Product Information
The automatic medicine box cartoner is a machine produced in strict accordance with the GMP requirements of the pharmaceutical industry on the basis of absorbing a number of advanced technologies at home and abroad. It has the characteristics of high stability, simple structure and convenient operation. Among them, our manual automatic folding and conveying, carton suction forming, multi-station servo belt speed pushing mechanism related technologies have reached the advanced level in the industry.
Features
The automatic medicine box cartoner adopts a simple appearance design, and is equipped with a multi-station servo belt-speed pushing structure, which is more convenient for operation and maintenance. The outer ring of the double-station planetary wheel is rotated and the outer box is opened and the pre-forming device can ensure that the box body is completely opened and formed. This machine is a fully automatic continuous packaging machine integrating light, electricity and gas. It is suitable for automatic packaging of aluminum-plastic blister boards, bottles, hoses, soft double aluminum, bags and other items, and can be combined with them. production line.
Specification
| Model: | KDZ-80 Automatic Medicine Box Cartoner | |
| Speed： | 30-100boxes/min | |
| Size range of cardboard box： | (70-220)mm * (14-90)mm *(14-65)mm | |
| Instruction book： | Paper material | 50-65g/m2 |
| Unfolded size range | （80-300）mm*(70-210)mm | |
| Folded size range | 1-4 folded (70-210)mm X (20-40)mm |
|
| Box material： | 250~450g/㎡ | |
| Main motor power： | 1.5 kw | |
| Power supply： | 380V 50Hz (220V 60 Hz) | |
| Work pressure： | 0.5-0.7 Mpa | |
| Compressed gas consumption: | ≥ 0.3m3/h | |
| Dimensions (length × width × height): | 3200×1200×1900mm | |
| Machine weight： | 2000 Kg | |
KEDE is one of China’s most professional Automatic Medicine Box Cartoner manufacturers and suppliers. Please feel free to wholesale customized Automatic Eye Drops Box Cartoning Machine at a competitive price from our factory. For discount information, contact us now.
