Overview
With the advent of the era of intelligence, packaging equipment such as automatic box folding machines and automatic bagging machines have gradually replaced a series of drawbacks brought by manual packaging. In particular, the carton forming machine has long been widely favored by people. This Automatic Hardware Box Cartoner adopts PLC programmable controller, photoelectric tracking system, hydraulic pneumatic system, touch screen man-machine interface, and implements processes such as automatic paper feeding, gluing, automatic cardboard conveying, and carton forming. Compared with traditional craftsmanship, the production efficiency has been increased by more than 30 times.
Features
Automatic Hardware Box Cartoner is manufactured with advanced technology at home and abroad, and is widely used in electronics, medical, food, cosmetics, hardware and other industries, with the following advantages:
1. The spare parts are all made of high-standard raw materials;
2. Beautiful appearance, durable, low failure rate, low energy and high efficiency, safe and reliable;
3. Compatible with different sizes of cartons, it only takes 10-15 minutes to manually change the size of the cartons.
Specification
| Model: | KDZ-100B Automatic Hardware Box Cartoner | |
| Speed： | 30-800boxes/min | |
| Size range of cardboard box： | (55-200)mm * (14-90)mm *(13-60)mm | |
| Instruction book： | Paper material | 50-65g/m2 |
| Unfolded size range | （80-300）mm*(70-210)mm | |
| Folded size range | 1-4 folded (70-210)mm X (20-40)mm |
|
| Box material： | 250~450g/㎡ | |
| Main motor power： | 1.5 kw | |
| Power supply： | 380V 50Hz (220V 60 Hz) | |
| Work pressure： | 0.5-0.7 Mpa | |
| Compressed gas consumption: | ≥ 0.3m3/h | |
| Dimensions (length × width × height): | 3500×1200×1900mm | |
| Machine weight： | 2000 Kg | |
We are a manufacturer of automatic cartoning machine equipment integrating mechanical research and development, intelligent manufacturing and marketing. The main products of factory are automatic packaging and cartoning machines for food, medicine, beauty products, daily necessities, and electronic products. as Automatic Hardware Box Cartoner suppliers, we can provide more competitive prices, and also support Customized Production Line.
