ZX-2000Double line vertical paper box machine
The machine is suitable for 3D carton forming, especially the carton of fast food industry, such as hamburger box, packing box and so on. Compared with the ordinary three-dimensional carton machine, the speed is fast, the feeding time is long, the collection of products, saving labor costs.
| model : | ZX-2000 | |
| speed: | 100-300pcs/min(Double line) | |
| Material: | 200-620gsm Corrugating paper thick:1.6mm |
|
| box size： | Length: | L100-450mm |
| Degree:5°-45° | ||
| Width: | B100-600mm | |
| Height: | H 15-200mm | |
| Power ： | 3.7kw | |
| Air requirement： | 0.5Mpa, 0.4cube/min | |
| power source: | 380V 50Hz | |
| size: | 2300*2200*2100mm | |
| weight： | 2000kgs | |
